KLK活塞壓力開關 / KLM隔膜密封壓力開關
Adjustment ranges 1...400 bar
KLK: Piston pressure switch KLM: Diaphragm seal pressure switch
無論您需要監控低壓還是高壓范圍，壓力開關 KLK 和 KLM 都能為您提供理想的解決方案。KLM 的可調調節范圍為 1 至 40 bar，KLK 的可調調節范圍為 30 至 400 bar，您可以靈活地滿足您的個性化需求。
KLM 是一款帶有一個開關觸點的隔膜密封壓力開關。它經過工廠設置，精度等級為滿量程的 2.0%。憑借其堅固的結構和隔膜密封系統，它非常適合要求苛刻的壓力應用。
另一方面，KLK 是一款活塞壓力開關，也提供一個開關觸點。它已在工廠設置并達到滿量程 1.0% 的精度等級。憑借其可靠的活塞系統，它可以精確監控高達 400 bar 的壓力。
Whether you need to monitor low or high pressure ranges, the pressure switches KLK and KLM provide you with the ideal solution. With adjustable adjustment ranges from 1 to 40 bar for the KLM and from 30 to 400 bar for the KLK, you have the flexibility to meet your individual requirements.
The KLM is a diaphragm seal pressure switch with one switching contact. It is factory set and offers an accuracy class of 2.0% full scale. With its robust construction and a diaphragm seal system, it is well suited for demanding pressure applications.
On the other hand, the KLK is a piston pressure switch that also provides one switching contact. It is factory set and achieves an accuracy class of 1.0% full scale. With its reliable piston system, it allows for precise monitoring of pressures up to 400 bar.
KLK活塞壓力開關 / KLM隔膜密封壓力開關
Adjustment ranges 1...400 bar
KLK: Piston pressure switch KLM: Diaphragm seal pressure switch
Features特征
KLM
- KLM隔膜密封壓力開關
- 調節范圍：1 ... 40 bar
- 1個開關觸點
- 工廠設定
- 精度等級 2.0 % f.s.
- Diaphragm seal Pressure Switch
- Adjustment range: 1 ... 40 bar
- 1 switching contact
- Factory set
- Accuracy class 2.0 % f. s.
KLK
- KLK活塞開關
- 調節范圍：30 ... 400 bar
- 1個開關觸點
- 工廠設定
- 準確度等級 1.0 % fs
- Piston Switch
- Adjustment range: 30 ... 400 bar
- 1 switching contact
- Factory set
- Accuracy class 1.0 % f. s.
應用領域
- 移動液壓系統 Mobile hydraulics
- 電機控制 Motor control
- 液壓夾緊 Hydraulic clamping
